Product Summary

The DG2535DQ-T1-E3 is a low voltage dual SPDT analog switch. It is suitable for cellular phones, speaker headset switching, audio and video signal routing, pcmcia cards, battery operated systems and relay replacement.

Parametrics

Absolute maximum ratings: (1)Reference to GND; (2)V+: - 0.3 to + 6 V; (3)IN, COM, NC, NOa: - 0.3 to (V+ + 0.3 V); (4)Continuous Current (NO, NC, COM): ±300 mA; (5)Peak Current: ±500 mA; (6)(Pulsed at 1 ms, 10% duty cycle); (7)Storage Temperature (D Suffix): - 65 to 150 ℃; (8)ESD per Method 3015.7: > 2 kV.

Features

Features: (1)Low Voltage Operation; (2)Low On-Resistance; (3)–69 dB OIRR at 2.7 V, 100 kHz; (4)MSOP-10 and DFN-10 Packages; (5)ESD Protection > 2000 V; (6)Latch-Up Current > 300 mA.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
DG2535DQ-T1-E3
DG2535DQ-T1-E3
Vishay Semiconductors
Analog Switch ICs Low Volt Dual SPDT
Data Sheet
0-1320: $0.68
1320-2500: $0.49
2500-5000: $0.47
5000-7500: $0.46
